MEGA 400 | 400 Watt Solar Panel | Premium Grid-tie or Off-grid Solar Panel for Residential, Commercial, Agriculture | 25-Year Output Warranty | UL Certified

Specifications & Downloads

• On Panel Cable Length
  ≈ 35 in
• Material
  Tempered Glass, Aluminum, Monocrystalline Silicon
• Dimensions
  67.9 x 44.6 x 1.2 in
• Weight
  49.4 lbs
• Maximum Power(Pmax)
  400W
• Maximum Power Voltage(Vmp)
  30.9V
• Maximum Power Current(Imp)
  12.9A
• Open Circuit Voltage(Voc)
  37.1V
• Short Circuit Current(Isc)
  13.7A
• Maximum System Voltage(Vmax)
  1500VDC

Features

• 10-busbar solar cell configuration
• Mono PERC Technology
• Lightweight anodized aluminum frame
• High-transmission, AR (anti-reflective) Coated Tempered Glass
• Plug-and-play junction box
• Industry-standard quick-connect cables work in series or parallel
• Certified to withstand challenging environmental conditions
• Excellent low-light performance on cloudy days, mornings, and evenings

Installation

• Easy installation and handling for various applications (high-end off-grid and mobile applications)
• Pre-drilled holes compatible with ground mounts, Z brackets, pole mounts, and tilt mounts
• Compatible with on-grid and off-grid inverters

Warranty

Check out our full Warranty page here for more information.
